TUNA 420 OC PL
“TUNA 420 OC PL” is the cockpit arrangement, in which only a single driver's console is installed. With a minimum comfort level the cockpit remains free and spacious to perform the fishing and hunting tasks.
| Design category | С |
| Power supply | 12 V DC |
| Carrying capacity, kg | 430 |
| Passenger capacity, pers. | 4 |
| Curb weight (max.), kg | 450 |
| Maximum engine weight, kg | 100 |
| Engine power recomm., h.p. | 30 |
| Engine power, h.p. | 40 |
| Fuel tank capacity, l | 50 (опция) |
| Dry weight (without engine), kg | 308 |
| Hull material | 5083 |
| Bilge thickness, mm | 3 |
| Deadrise amidships, ° | 17 |
| Deadrise at transom, ° | 8 |
| Transom height, m | 0,38/0,51 |
| Depth, m | 0,775 |
| Draft, m | 0,26 |
| Height overall, m | 1,3 |
| Beam waterline, m | 1,5 |
| Beam overall, m | 1,77 |
| Length waterline, m | 3,5 |
| Length of hull, m | 4,2 |
| Length overall, m | 4,2 |
