QUORUM 23 SE

With the capacity to carry up to 11 people, you will love the styling and comfort of this 23’-8’’ Quorum 23 SE. While you can gear it with a 250 HP engine (with the Performance configuration) to enjoy all your water sports, you can also rig this pontoon with a 40 HP engine, perfect for smaller lakes or to simply relax on the water. With such features as an aft bar section with corner module, adjustable bar stools, tons of storage, rear swim platform, a chaise lounge, and a lot more, you will most definitely not find anything comparable.

GENERAL SPECIFICATIONS

  • Overall length : 7.2 m (23'-8'')
  • Deck length : 6.9 m (22'-8'')
  • Beam : 2.6 m (8'-6'')
  • Pontoon length : 6.8 m (22'-4'')
  • Pontoon diameter : 0.64 m (25'')
  • Pontoon aluminum thickness : 2.0 mm (.080'')
  • Approximate weight : 947 kg (2088 lb.)
  • Maximum HP capacity : 112 kW (150 HP)
  • Maximum weight capacity : 973 kg (2144 lb.)
  • Maximum weight person capacity : 672 kg (1482 lb.)
  • Maximum person capacity : 11
  • Maximum HP capacity : 112 kW (150 HP)
  • Maximum weight cap.acity : 973 kg (2144 lb.)
  • Maximum weight person capacity : 672 kg (1482 lb.)
  • Maximum person capacity : 11
  • Built-in : 110 L (29 U.S. gal.)

CONSTRUCTION FEATURES

  • 5052-H36 marine grade aluminum alloy
  • NMMA & Transport Canada certified
  • 2 ½" heavy-duty extruded Z-aluminum cross channels
  • 1 1/4" anodized aluminum rails
  • Sealed pontoon bulkheads with top mounted air plug (25")
  • V-shaped aluminum engine pod
  • Pressure-treated wood deck covered with marine grade carpet
  • Extruded aluminum full-length pontoon keels
  • Extruded aluminum full-length pontoon skirting
  • Stern molded corners
  • Walk-thru bow gate with lift and lock hinges
  • Walk-thru rear gate with lift and lock hinges
  • Port side gate with lift and lock hinges
  • Rear swim platform
  • Stainless steel bow eye
  • Lifting eyes
  • 4- 6" chromed deck cleats
  • Fiberglass helm console with integrated cooler
  • Molded dash panel with black pearl woodgrain inserts and lighted switches
  • Sport tilt steering mechanism
  • 160-watt AM/FM/Bluetooth Jensen Stereo with integrated auxiliary input (1/8") in console
  • 4 waterproof speakers ( 6 ½" )
  • Electric horn
  • 12V outlet
  • Push on/off console courtesy light
  • LED lighting under driver console
  • Quick release smoked windscreen
  • Tachometer, voltmeter, speedometer, trim and fuel gauges
  • Plush and heavy weight upholstery
  • Roto-Cast furniture bases and backs
  • 2 Roto-Cast portable padded armrests trimmed in black pearl woodgrain with cup holders
  • Captain's chair on slide and swivel
  • 1 chaise lounge
  • Bar section including corner module, cooler storage, 12 volt outlet, and 4 stools
  • Big storage under the Bar section
  • Storage in chaise lounge's reclined section
  • 2 storage pouches
  • Storage under all lounges
  • Color coordinated or taupe bimini top
  • Quick release bimini top latches and traveling struts
  • Factory installed canvas camper enclosure & mooring cover snap fasteners
  • Stern boarding ladder
  • Cup holders
  • Bow chromed corner light housings
  • Navigation lights
  • Raised chromed letter logos
  • Transducer mounting bracket
  • Battery box

FACTORY INSTALLED OPTIONS

  • Speed Configuration for 2-log models: lifting strakes and under-deck spray shield
  • Sport Configuration: bow central half 3rd log, lifting strakes and under-deck spray shield
  • Performance Configuration: 3rd log, under-deck spray shield, lifting strakes, 49 U.S. gal. / 185 L gas tank and 1 in-floor storage compartment
  • Under-deck spray shield (for 2-log models only)
  • Elegance Edition: Elegance Edition logo on both sides, Elegance graphic package with color accent, monochrome upholstery, LED lighting on logs, speakers and cup holder in console, stern black pearl woodgrain table, stern stainless steel telescopic ladder, and stern swim platform with "Select" vinyl, and LED lighting under the counters
  • Convenience Package: docking lights, depth finder gauge, console galley conversion, and reclining captain's chair
  • Anti-skid vinyl floor covering...upgrade exchange
  • Select anti-skid vinyl floor covering...upgrade exchange
  • Sea Star hydraulic steering system with tilt wheel (included with 150 HP engine and up)... upgrade exchange
  • Stainless steel telescopic stern boarding ladder..upgrade exchange
  • Head on slider with holding tank and pump out (9.8 L / 2.6 U.S. gal.)
  • Monochrome upholstery...upgrade exchange
  • Fiberglass raised helm
  • 200-watt AM/FM/CD/Bluetooth Clarion Stereo compatible SAT with integrated USB plug and auxiliary input (1/8") in console...upgrade exchange
  • Lowrance depth finder gauge with water temperature
  • SmartCraft gauges (tachometer, speedometer and trim)...upgrade exchange
  • Active trim: automatic trim system
  • Underwater lighting (2 lights)
  • Raised rail upgrade
  • 12-volt, 2.7 cubic foot self ventilated galley refrigerator and 12V battery charger (ProSport 6)
  • Stainless steel waterski tow bar
  • Pop-up privacy enclosure
  • Bow beige pedestal mount removable snack table with chromed cup holders
  • Bow black pearl woodgrain rectangular pedestal mount removable snack table with chromed drink holders
  • Barbecue (BBQ) gas grill
  • Inflatable bow filler cushion with 12 V DC or 120 V AC inflation pump, storage bag and patch kit
  • Removable chromed cup holders trimmed in woodgrain
  • Battery switch (allowing the onboard power shut down)
  • Trailer cover
  • Mooring cover
  • Double bimini top
  • Half camper enclosure with front cockpit cover
  • Conversion kit for half camper enclosure into a full camper enclosure
  • Full camper enclosure
  • Magnetic Gray with True Mica Mist "Magnitude" Carpet (24 oz.) and Vinyl on the rear platform
  • Black with True Mica Mist "Magnitude" Carpet (24 oz.) and Vinyl on the rear platform
  • Aztec Red with True Mica Mist "Magnitude" Carpet (24 oz.) and Vinyl on the rear platform
  • Mercury 40 ELPT CT 4S
  • Mercury 50 ELPT CT 4S
  • Mercury 60 ELPT CT 4S
  • Mercury 75 ELPT 4S
  • Mercury 90 EXLPT CT 4S
  • Mercury 115 EXLPT CT 4S
  • Mercury 115 EXLPT PRO XS CT 4S
  • Mercury 90 EXLPT CT 4S
  • Mercury 115 EXLPT CT 4S
  • Mercury 115 EXLPT PRO XS CT 4S
  • Mercury 150 XL 4S
  • Mercury 90 EXLPT CT 4S
  • Mercury 115 EXLPT CT 4S
  • Mercury 115 EXLPT PRO XS CT 4S
  • Mercury 150 XL 4S
  • Mercury 175 L Verado L4
  • Mercury 150 XL 4S
  • Mercury 175 L Verado L4
  • Mercury 200 L Verado L4
  • Mercury 200 L Verado L6 Pro
  • Mercury 225 L Verado L6
  • Mercury 250 L Verado L6 Pro
  • 6922047-GALVANIZED TANDEM AXLE SCISSOR-LIFT STYLE TRAILER WITH BRAKES (FOR 2 LOGS ONLY)
  • Sealed hubs, swivel tongue jack and 2" ball coupler
  • Drum brakes (on all axles)
  • Factory balanced wheels
  • Tire size : 5.30 X 12'' C
  • Weight : 293 kg (645 lb.)
  • 1607 kg (3535 lb.) carrying capacity
  • 6934047-GALVANIZED TANDEM AXLE BUNK SUPPORT STYLE TRAILER WITH BRAKES
  • Carpeted fixed bunks
  • Sealed hubs, swivel tongue jack and 2" ball coupler
  • Drum brakes (on all axles)
  • Factory-balanced wheels
  • LED lights
  • Tire size: 20.5 x 8 x 10'' C
  • Weight : 439 kg (966 lb.)
  • 1571 kg (3456 lb.) carrying capacity
  • 6935047-GALVANIZED TANDEM AXLE BUNK SUPPORT STYLE TRAILER WITH DISC BRAKES (must be equipped with the Conversion kit for 3-log models)
  • Carpeted fixed bunks
  • Sealed hubs, swivel tongue jack and 2" ball coupler
  • Disc brakes (on all axles)
  • Factory-balanced wheels
  • LED lights
  • Tire size: ST175/80R13C
  • Weight : 460 kg (1012 lb.)
  • 2013 kg (4429 lb.) carrying capacity
  • 6935087-GALVANIZED TRIDEM AXLE BUNK SUPPORT STYLE TRAILER WITH DISC BRAKES (must be equipped with the Conversion kit for 3-log models)
  • Carpeted fixed bunks
  • Sealed hubs, swivel tongue jack and 2" ball coupler
  • Disc brakes (on all axles)
  • Factory-balanced wheels
  • LED lights
  • Tire size: ST175/80R13C
  • Weight : 530 kg (1168 lb.)
  • 3178 kg (6991 lb.) carrying capacity

TRAILER OPTIONS

  • Conversion kit for 3-log models
  • Deluxe transom tie downs…/pair
  • Galvanized spare wheel 20.5 x 8.0 x 10" C and bracket
  • Galvanized spare wheel 5.30 x 12" C with 5 lugs and bracket
  • Galvanized spare wheel ST175/80R13 C radial with 5 lugs and bracket
